Customized Lithium Ion Battery Pack LifePo4 24V 48V 200Ah Powerwall battery For Solar Home Energy Storage System


Price	Negotiable
MOQ	1 unit
Delivery Time	7-15 working days
Brand	CLF
Place of Origin	Hunan,China
Certification	UN38.3, MSDS,CE
Model Number	CLF-R0068
Packaging Details	Wooden case and Carton case
Payment Terms	T/T
Supply Ability	1000 units per month

Product Details

Product Specification

Place of Origin	Hunan,China	Battery type	Lifepo4/lithium Battery
Packaging Details	Wooden case and Carton case	Color	Can custom logo
Model Number	CLF-R0068	Combination method	8S2P
Supply Ability	1000 units per month	Appearance	Without distortion and scratches
Certification	UN38.3, MSDS,CE	Weight	55KG
Brand Name	CLF	Payment Terms	T/T
Price	Negotiable	Delivery Time	7-15 working days
Capacity	100Ah	Minimum Order Quantity	1 unit
Voltage	51.2V	Communication Mode	RS485
Application	Home Appliances, Electric Power Systems,	OEM/ODM	Acceptable
Dimensions(L×W×H)	600395220mm

Product Description

PACKAGING & ACCESSORIES

①Open the package, inspect product accessories, including:1 host,1 piece user manual

②Inspect whether the machine have been damaged during the transport or not, If it have some damage, don’t start the machine, please contact us.

INTERNAL DETAILS

PRODUCT DETAIL

PRODUCT ADVANTAGES





          High
          Discharge
          Rate
          High
          Pulse
          Energy,
          Safe
          and
          Reliable
          Long
          Cycle
          Life
          Smart
          Seamless
          Switching


PRODUCT SPECIFICATION

NO	Item	Specifications	Notes
1	Nominal Capacity	160Ah	Standard dischargeafter Standard charge
2	Combination method	8S2P
3	Weight	Approx:55kg
4	Nominal voltage	25.6V
5	Charge limit voltage	29.2V
6	Discharge cut-off voltage	20V
7	Standard charge current	0.2C	0℃~55℃
8	Maximum charge current	150A	10℃~55℃
9	Standard discharge current	0.5C	- 10℃~55℃
10	Maximum discharge current	150A	10℃~55℃
12	Operating temperature	0℃~55℃	Charging
		-10℃~55℃	Discharging
	Storage temperature	- 10℃~ +45℃	less than 1 month	Recommended storage temperature: 25℃,at the shipment state
		- 10℃~ +35℃	less than 6 months
13	Recoverable capacity	Constant current 0.2C charge to 29.2V,then constant voltage 29.2Vcharge to current declines to 0.02C, rest for 10min ,constant current 0.5C discharge to 20V,rest for 10min.Repeat above steps 3 times,recording the maximum capacity.
14	Cycle Performance	11
15	Storage Hu mid ity	≤75% RH
12	Operating temperature	0℃~55℃	Charging
		-10℃~55℃	Discharging
	Storage temperature	- 10℃~ +45℃	less than 1 month	Recommended storage temperature: 25℃,at the shipment state
		- 10℃~ +35℃	less than 6 months
13	Recoverable capacity	Constant current 0.2C charge to 29.2V,then constant voltage 29.2Vcharge to current declines to 0.02C, rest for 10min ,constant current 0.5C discharge to 20V,rest for 10min.Repeat above steps 3 times,recording the maximum capacity.
14	Cycle Performance	11
15	Storage Hu mid ity	≤75% RH
16	Appearance	Without distortion and scratches
17	Standard testing condition	Temperature:25±2℃ Humidity:≤75%RH Atmospheric Pressure:86- 106 Kpa
